薄膜耳料回收机系列- 边料回收机
·主要配置特点
边料回收机JY-123 /163 用途：螺杆45MM以上的押出机回收耳料适用之一。
功能：针对小型押出机或较宽PP、PE、HLPE、LOPE、缩收膜、PE保鲜膜……等薄膜、起泡布的耳料100%粉碎立即回收。
处理功能：厚度0.01-0.08MM宽度30MM以下的耳料。
本系列产品采用钨钢也粉碎，用下常情况下比一般粉碎也寿命长10倍，使用时间约为4年，才需要更换研磨使用。
·The main features
Use :Use for recycling ear material of extruder with
Above 45mm screw.
Function:crush and immediately recycle at 100%
Specifying for small-scale extruder or more wider PP,
and other thin films,ear materials of foaming cloth.
Processing function:the ear material with thickness
Of0.01-0.008mm and width of low 30mm.
These series products adopt tungsten steel to crush
Materials.Normally,the operation life is longer 10.
Times than general crushing;the working life is about
400work days,and it needs replacing grind for usage.
规格参数Specification parameter
|
机型Models
|
单位Unit
|
Jy123
|
Jy163
|
|
粉碎马达
Grinding Motor
|
HP
|
1
|
3
|
|
回转直径
Swinging Diameter
|
mm
|
130
|
180
|
|
刀长
Blower Motor
|
mm
|
123
|
163
|
|
固定刀数
Number Of Fixed Blade
|
Pc/set
|
2
|
2
|
|
回转刀数
Number Of Rotary Cutter
|
Pc/set
|
3
|
3
|
|
筛网孔径
Mesh Size
|
mm
|
3-5
|
3-6
|
|
风车马达
Blower Motor
|
HP
|
2
|
2
|
|
工作量
Workload
|
kgs/nr
|
15-30
|
25-60
|
|
输送螺杆马达
Conveyor Screw Motor
|
HP
|
1/2
|
1
|
|
旋风分离器直径
Cyclone Separator
|
mm
|
250
|
250
|
|
长×宽×高
L×W×H
|
mm
|
100×550×950
|
1050×600×1050
|
|
包装尺寸
Package Size
|
mm
|
1100×900×800
|
1200×1000×1100
|
|
重量
Weight
|
KGS
|
180
|
300
|
